M-400 ATC Mill Control from Machines in Motion

     Centroid's full-featured M-400 ATC mill control comes standard
     with 3 servomotors (sized to fit your machine tool application)
     and is upgradeable to 4-Axis for a rotary table or an additional
     linear axis. The M-400 ATC includes an integrated jog panel to
     simplify your workspace. Centroid CNC controls are built with a
     standard high speed PC and DSP secondary processor.
     The crystal-clear 15" LCD display reduces eye strain during
     programming or running a job. The M-400 ATC handles
     The inputs and outputs needed to process automatic tool
     changes. PLC I/O for spindle control and orient are also pre-
     programmed. Machines in Motion will smooth over all the
     details to provide you with a turnkey installation in just days.

     Smart Search allows mid program interrupt. Then restart anywhere in the program.
     High Speed Machining for 3D surfaces by providing maximum accel/decel.
     Advanced Color Graphics to view parts on screen (visual dry run) before running the job.
     Programming errors are presented on screen in plain english prior to cutting your part.
     Conversational programming software & a Fanuc G-code text editor are standard.
     Canned cycles for drilling, milling, pocketing, and thread milling are built in.
     Large operator's display screen. Centroid's high resolution, non glare,
     color LCD screen displays: tool position (DRO) at all times. On-screen values for spindle RPM,
     cutting feedrate, and a parts counter with timer. While viewing a program graphically,
     you can distinguish between rapid moves, feedrate moves, and cutter comp moves.

     Enter part programs directly from the
     dimensions on your blueprint. Easy "fill in
     the blank" menus generate industry
     standard G-Code programs automatically
     on your shop floor. Centroid's Teach Mode
     also easily creates programs from existing
     parts.
     Off-line programming Centroid's
     conversational programming is available in
     an optional off-line (Windows friendly) format.
     Program your parts with ease from the
     comfort of your PC while your machine
     continues to produce.

Cut threads on your part from the push
of a button. Use canned cycles to make
everyday jobs a snap. Choose bolt hole
patterns, facing, rectangular, circular,
and irregular pockets with cleanout. Use
repeat to duplicate whole parts, make a
matrix of holes, or repeat a contour to
depth with just a few key strokes. Mirror,
rotate, and scale your part right at the
control.


    See graphics as you work, even for partially
    completed programs. Compare your work to
    the blueprint with the touch of a button then get
    back to your programming.

Use high speed machining for 3D
surfaces, cutting EDM electrodes,
and artistic shapes. Complex 3D
CAD/CAM or engraving programs
can be run at high speeds without
hesitation. A high throughput block rate
combined with 2000 block Accel/Decel
look ahead allows fast cuts while holding
tight tolerances.


     Setup parts in seconds. On screen "how-to"
     graphics and menu selections make operating
     a Centroid CNC control as simple as it could
     possibly be.

     Using the optional probing feature will further
     reduce your part setup time and increase your
     overall accuracy!

Copy and cut 3D parts with Centroid's Digitizing. Simple,
accurate, and everything you need in one package. No extra
computer is needed. Digitizing automatically generates and
stores the part program on the controls hard drive. Cut the part immediately or export the data file to your off-line CAD/CAM
system for editing. You can also process your digitized part file
through Centroid's included "Mold Magic" software. Mold Magic
will produce auto-roughing pass program files or use it to reverse
image the part creating a mold from a plug or vice versa.
No CAD/CAM is needed. When purchased from Machines in
Motion this terrific software is included at no additional charge
with your purchase of Centroid's digitizing package.

          Automatic Tool Setter

          Centroid's automatic tool setter makes measuring tool length
          offsets accurate and quick. Press one button to measure your
          entire ATC carousel. On screen prompts guide you through the
          process with simple push button operations.


  Precision spindle speed and Z-axis control allows the use of solid tool
  holders with your tap. Includes deep hole cycles with peck tapping.




                                       Network Communications

  Connect your Centroid control to a network via our RJ-45 ethernet
  interface. This standard feature allows program files to be transferred
  to and from memory with ease, leaving your machine to do the work
  while you program from an off-line PC.


Centroid's optional 4th axis can either be a rotary or a linear axis.
This true 4th axis moves simultaneously with any other axis (full 4th
axis interpolated motion) and can be easily programmed fro
Centroid's Intercon Conversational, G-codes, or CAD/CAM.
Centroid also offers an extensive line of quality rotary tables.
Why buy a plain indexer when you can have a full contouring
controlled axis?

          Find bore and boss centers, fixture offsets, and corners of
          vises fast, accurately, and from the push of a button. Whether
          establishing fixture offsets, defining part zero, or finding an
          edge, probing cycles can do it faster and with greater
          precision than simple indicators.

O.E.M. control of choice
for many machine manufactures
